RefLED Retro ES111 V3 1150LM DIM 830 25SL
Item No:
0031858
High performance LED ES111 lamp with the same look and feel of traditional Haloegn ES111 lampFull glass design - means no colours clashing between lamp and fixtureHigh lumen output - 1150lmStippled lens to help reduce glare and recreate the halogen light effect25° beam angle96% energy savingDimmable25,000 H average rated life, last 12.5 times longer than halogen alternatives> 100,000X switching cycleHigh lumen efficacy – 89 lm/WGood colour rendering - CRI 80
Technical Assets
Dimensions (mm)
Photometrics
Product name
RefLED Retro ES111 V3 1150LM DIM 830 25SL
Technology
LED
Watt (Rated) (W)
12
Lamp shape
Reflector
Cap/Base
GU10
Lamp finish
Clear
Built in presence detector
NONE
Fixture rating
Open
General application
Hospitality, Museums & Galleries, Residential & Consumer, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
Virtual assistant compatibility
N/A
ETIM Class
EC001959
E-number FI
4741297
Warranty
3 years
Useful luminous flux (Φuse)
1150
Correlated colour temperature (k)
3000
Light colour
Warm White
CRI (Ra)
80
Colour Consistency (SDCM)
6
Colour Variation Initial (SDCM)
SDCM6
Luminous Intensity (cd)
3200
Beam Angle (°)
25
Photobiological Risk Group
RG1
Lumen maintenance at end of nominal life (%)
70
Power consumption (W)
12
Wattage (W)
12
Equivalent watt (W)
140
Supply current (A)
0.054
Primary Supply/Product voltage - min (V)
220.0
Primary Supply/Product voltage - max (V)
240.0
Control gear required
No
Control gear type
LED driver constant current
No. Of switching cycles before premature failures
>100000
Dimmable
Yes
Dimming method
Mains: leading / trailing edge
Inrush Current (A)
2.3
Inrush Duration (µs)
110
Lamp Energy Label (class)
E
Nominal Frequency (Hz)
50/60Hz
Max. products per 16A C Breaker
182
Max. products per 16A B Breaker
182
Lifespan L70 B50
25000
Average life (Nominal) (h)
25000
Average life (Rated) (h)
25000
Housing colour
Silver
IP rating
IP20
Nominal Product Height (mm)
69
Nominal Product Diameter (mm)
110
Weight (kg)
0.22
Product EAN number
5410288318585
Packaging single length / height (cm)
11.5
Packaging single width (cm)
11.5
Packaging single depth (cm)
9.0
DUN14 (inner)
15410288318582
Units per outer package
6
Packaging outer length / height (cm)
36.3
Packaging outer width (cm)
24.5
Packaging outer depth (cm)
11.5
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Not Suitable for totally enclosed fixtures
