RefLED Retro MR11 184LM 830 36° SL
Item No:
0031830
LED MR11 range with the same look and feel of traditional halogen MR11 lampFull glass design - means no colours clashing between the lamp and fixtureAvailable in 36 degree beam angle15,000 hours average rated lifeSwitching cycles: 50,000Colour rendering: CRI80Lamp voltage: 12V AC/DCWorks with magnetic and compatible electronic transformers*Warranty: 3 Years
Downloads
Technical Assets
Dimensions (mm)
Photometrics
Product name
RefLED Retro MR11 184LM 830 36° SL
Technology
LED
Watt (Rated) (W)
2.5
Lamp shape
Reflector
Cap/Base
GU4
Lamp finish
Clear
Built in presence detector
NONE
Fixture rating
Open
General application
Education, Hospitality, Museums & Galleries, Office, Residential & Consumer, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
Virtual assistant compatibility
N/A
ETIM Class
EC001959
E-number FI
4741294
Warranty
3 years
Useful luminous flux (Φuse)
184
Correlated colour temperature (k)
3000
Light colour
Warm White
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Colour Consistency (SDCM)
6
Luminous Intensity (cd)
400
Beam Angle (°)
36
Photobiological Risk Group
RG1
Lumen maintenance at end of nominal life (%)
70
Power consumption (W)
2.5
Wattage (W)
2.5
Equivalent watt (W)
20
Supply current (A)
0.341
Primary Supply/Product voltage - min (V)
12.0
Primary Supply/Product voltage - max (V)
12.0
Control gear required
Yes
Control gear type
Electronic transformer (Halogen)
No. Of switching cycles before premature failures
>100000
Dimmable
No
Dimming method
N/A
Inrush Current (A)
8
Inrush Duration (µs)
500
Lamp Energy Label (class)
G
Nominal Frequency (Hz)
50/60/HF
Max. products per 16A C Breaker
32
Max. products per 16A B Breaker
20
Lifespan L70 B50
15000
Average life (Nominal) (h)
15000
Average life (Rated) (h)
15000
Housing colour
Transparent
IP rating
IP20
Nominal Product Height (mm)
38
Nominal Product Diameter (mm)
35
Weight (kg)
0.014
Product EAN number
5410288318301
Packaging single length / height (cm)
5.0
Packaging single width (cm)
4.5
Packaging single depth (cm)
7.5
DUN14 (inner)
15410288318308
Units per inner package
6
Packaging inner length / height (cm)
15.9
Packaging inner width (cm)
9.9
Packaging inner depth (cm)
8.8
DUN14 (outer)
25410288318305
Units per outer package
36
Packaging outer length / height (cm)
31.5
Packaging outer width (cm)
17.1
Packaging outer depth (cm)
19.6
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Suitable for approved transf./dimmers
