ToLEDo RT G9 V2 CL 470LM DIM 865 SL
Item No:
0030789
LED retrofit replacement for halogen G9 mains voltage capsulesToLEDo Retro G9 has the same look and feel as halogen design thanks to glass construction body and wide light distributionCompact designOmni-directional light distributionHigh lumen efficacy: up to 131lm/WUp to 91% energy savingDimmable and non-dimmable versionsSuitable for chandeliers, interior display, shop windows, decorative and general lighting applications
Downloads
.jpg?maxwidth=1200&maxheight=1200&trim.threshold=250)
.jpg?maxheight=100&trim.threshold=200)
.jpg?maxheight=100&trim.threshold=200)
Technical Assets
Dimensions (mm)
Photometrics
Product name
ToLEDo RT G9 V2 CL 470LM DIM 865 SL
Technology
LED
Lamp shape
Capsule
Cap/Base
G9
Lamp finish
Clear
Built in presence detector
NONE
Fixture rating
Open
General application
Hospitality, Residential & Consumer
Operating temperature range (°C)
-20°C...+40°C
Virtual assistant compatibility
N/A
ETIM Class
EC001959
E-number FI
4741211
Warranty
3 years
Useful luminous flux (Φuse)
470
Correlated colour temperature (k)
6500
Light colour
Daylight
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Beam Angle (°)
285
Photobiological Risk Group
RG1
Power consumption (W)
4.4
Wattage (W)
4.4
Equivalent watt (W)
40
Supply current (A)
0.032
Primary Supply/Product voltage - min (V)
220.0
Primary Supply/Product voltage - max (V)
240.0
Control gear required
No
Control gear type
LED driver constant current
No. Of switching cycles before premature failures
>50000
Dimmable
Yes
Dimming method
Mains: leading / trailing edge
Inrush Current (A)
3.24
Inrush Duration (µs)
7100
Lamp Energy Label (class)
F
Nominal Frequency (Hz)
50Hz
Lifespan L70 B50
15000
Housing colour
Transparent
IP rating
IP20
Nominal Product Height (mm)
55.5
Nominal Product Diameter (mm)
18
Weight (kg)
0.011
Product EAN number
5410288307893
Packaging single length / height (cm)
6.1
Packaging single width (cm)
5.1
Packaging single depth (cm)
8.2
DUN14 (inner)
15410288307890
Units per outer package
6
Packaging outer length / height (cm)
19.5
Packaging outer width (cm)
11.0
Packaging outer depth (cm)
9.5
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Not Suitable for totally enclosed fixtures
