ToLEDo GLS 806LM 827 B22 SL10 RW
Item No:
0029698
Compact and elegant designSuitable replacement for halogen, incandescent and compact fluorescent lampsInstant light at the flick of a switchUniform light distributionGood colour rendering (CRI 80)Perfect for hotels, restaurants, lobbies, corridors, stairwells, reception areasLower maintenance costs12,000 hours average rated life
Technical Assets
Dimensions (mm)
Photometrics
Product name
ToLEDo GLS 806LM 827 B22 SL10 RW
Technology
LED
Watt (Rated) (W)
8
Lamp shape
Pear-shape
Cap/Base
B22
Lamp finish
Opal
Fixture rating
Open
General application
Residential & Consumer
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
Virtual assistant compatibility
N/A
ETIM Class
EC001959
Warranty
2 years
Useful luminous flux (Φuse)
806
Luminous flux (Rated) (lm)
806
Correlated colour temperature (k)
2700
Light colour
Homelight
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Photobiological Risk Group
RG0
Lumen maintenance at end of nominal life (%)
70
Power consumption (W)
8
Wattage (W)
8
Equivalent watt (W)
60
Primary Supply/Product voltage - min (V)
220
Primary Supply/Product voltage - max (V)
240
Control gear required
No
No. Of switching cycles before premature failures
>100000
Dimmable
No
Inrush Current (A)
3.2
Inrush Duration (µs)
350
Lamp Energy Label (class)
F
Nominal Frequency (Hz)
50/60Hz
Max. products per 16A C Breaker
50
Max. products per 16A B Breaker
25
Lifespan L70 B50
15000
Average life (Nominal) (h)
15000
Average life (Rated) (h)
15000
Housing colour
White
IP rating
IP20
Nominal Product Length (mm)
107
Nominal Product Diameter (mm)
60
Weight (kg)
0.576
Product EAN number
5410288296982
Packaging single length / height (cm)
26.5
Packaging single width (cm)
12.0
Packaging single depth (cm)
22.5
DUN14 (inner)
15410288296989
Units per outer package
3
Packaging outer length / height (cm)
37.2
Packaging outer width (cm)
27.6
Packaging outer depth (cm)
24.0
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Not Suitable for totally enclosed fixtures
