ToLEDo GLS V7 1055LM 840 E27 SL4
Item No:
0030992
Compact and elegant designSuitable replacement for halogen, incandescent and compact fluorescent lampsInstant light at the flick of a switchUniform light distributionGood colour rendering (CRI 80)Perfect for hotels, restaurants, lobbies, corridors, stairwells, reception areasLower maintenance costs15,000 hours average rated life
Technical Assets
Dimensions (mm)
Photometrics
Product name
ToLEDo GLS V7 1055LM 840 E27 SL4
Technology
LED
Watt (Rated) (W)
9.5
Lamp shape
Pear-shape
Cap/Base
E27
Lamp finish
Opal
Built in presence detector
NONE
Fixture rating
Open
General application
Hospitality, Residential & Consumer
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
Virtual assistant compatibility
N/A
ETIM Class
EC001959
E-number FI
4741278
Warranty
3 years
Useful luminous flux (Φuse)
1055
Luminous flux (Rated) (lm)
1055
Correlated colour temperature (k)
4000
Light colour
Cool White
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Photobiological Risk Group
RG0
Lumen maintenance at end of nominal life (%)
70
Power consumption (W)
9.5
Wattage (W)
9.5
Equivalent watt (W)
75
Supply current (A)
0.075
Primary Supply/Product voltage - min (V)
220.0
Primary Supply/Product voltage - max (V)
240.0
Control gear required
No
Control gear type
LED driver constant current
No. Of switching cycles before premature failures
>100000
Dimmable
No
Dimming method
N/A
Inrush Current (A)
4
Inrush Duration (µs)
380
Lamp Energy Label (class)
E
Nominal Frequency (Hz)
50/60Hz
Max. products per 16A C Breaker
40
Max. products per 16A B Breaker
20
Lifespan L70 B50
15000
Average life (Nominal) (h)
15000
Average life (Rated) (h)
15000
Housing colour
White
IP rating
IP20
Nominal Product Length (mm)
109
Nominal Product Diameter (mm)
60
Weight (kg)
0.136
Product EAN number
5410288309927
Packaging single length / height (cm)
21.0
Packaging single width (cm)
11.2
Packaging single depth (cm)
6.1
DUN14 (inner)
15410288309924
Units per outer package
6
Packaging outer length / height (cm)
37.7
Packaging outer width (cm)
21.6
Packaging outer depth (cm)
12.0
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Not Suitable for totally enclosed fixtures
