RefLED ES50 XL V4 345LM 830 36 SL
Item No:
0028585
Perfect for consumers and contractors looking for LED solutions to replace halogenGU10 in the most efficient and economical way, while maintaining a similar visual appearance and brightnessAvailable in non-dimmable versions in popular Homelight (2700K) colour temperature and is backed by a 3-year warranty for complete peace of mind.
Downloads
Technical Assets
Dimensions (mm)
Photometrics
Product name
RefLED ES50 XL V4 345LM 830 36 SL
Technology
LED
Watt (Rated) (W)
4.2
Cap/Base
GU10
Fixture rating
Open
General application
Hospitality, Museums & Galleries, Residential & Consumer, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
ETIM Class
EC001959
Warranty
3 years
Useful luminous flux (Φuse)
345
Correlated colour temperature (k)
3000
Light colour
Warm White
CRI (Ra)
80
Colour Consistency (SDCM)
6
Colour Variation Initial (SDCM)
SDCM6
Luminous Intensity (cd)
770
Beam Angle (°)
36
Photobiological Risk Group
RG1
Lumen maintenance at end of nominal life (%)
70
Power consumption (W)
4.2
Wattage (W)
4.2
Equivalent watt (W)
50
Starting time (max) (s)
＜0.5
Warm-up time to 60% of full light (max) (s)
＜1.0
Primary Supply/Product voltage - min (V)
220
Primary Supply/Product voltage - max (V)
240
Lamp power factor
1
Control gear required
No
No. Of switching cycles before premature failures
>50000
Dimmable
No
Inrush Current (A)
3.9
Inrush Duration (µs)
4100
Lamp Energy Label (class)
F
Nominal Frequency (Hz)
50/60Hz
Max. products per 10A C Breaker
14
Max. products per 16A C Breaker
288
Max. products per 20A C Breaker
28
Max. products per 16A B Breaker
173
Lifespan L70 B50
15000
Average life (Nominal) (h)
15000
Average life (Rated) (h)
15000
Nominal Product Length (mm)
75
Nominal Product Diameter (mm)
50
Weight (kg)
0.023
Product EAN number
5410288285856
Packaging single length / height (cm)
6.1
Packaging single width (cm)
5.1
Packaging single depth (cm)
9.0
DUN14 (inner)
15410288285853
Units per outer package
6
Packaging outer length / height (cm)
19.5
Packaging outer width (cm)
11.3
Packaging outer depth (cm)
10.5
Optimal operating condition (°C)
-20-40
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Not Suitable for totally enclosed fixtures
