REFLED PLATINUM RETRO ES50 360LM DIM 830 36 SL
Item No:
0031925
Ultra-efficient LED GU10 range with the same look and size as traditional GU10 lamp. Save up to 95% on energy bills compared to halogen GU10 lamps. Energy Class A and best-in-class lumen efficacy. Sustainable and eco-friendly solution. Recreates backlight effect like halogen dichroic GU10 lamps. Full glass design - means no colours clashing between lamps and fixture. Last three times longer than the standard LED retrofit lamps. Remarkable 50,000 hours average rated life – reducing the hassle of frequent replacements. COOLFIT functionality – ensures overheating and overtemperature protection. Ideal for everyday lighting in homes, hotels, restaurants and more. Dimmable.
Technical Assets
Dimensions (mm)
Photometrics
Product name
REFLED PLATINUM RETRO ES50 360LM DIM 830 36 SL
Technology
LED
Lamp shape
Reflector
Cap/Base
GU10
Lamp finish
Fresnel lens
Built in presence detector
NONE
Fixture rating
Open
General application
Residential & Consumer, Education, Hospitality, Museums & Galleries, Office, Residential & Consumer, Retail
Virtual assistant compatibility
N/A
ETIM Class
EC001959
Warranty
5 years
Useful luminous flux (Φuse)
360
Correlated colour temperature (k)
3000
Light colour
Warm White
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Luminous Intensity (cd)
750
Beam Angle (°)
36
Photobiological Risk Group
RG1
Power consumption (W)
2
Wattage (W)
2
Equivalent watt (W)
50
Supply current (A)
0.016
Primary Supply/Product voltage - min (V)
220.0
Primary Supply/Product voltage - max (V)
240.0
Lamp power factor
0.5
Control gear required
No
Control gear type
LED driver constant current
No. Of switching cycles before premature failures
>50000
Dimmable
Yes
Dimming method
N/A, Mains: leading / trailing edge
Inrush Current (A)
3.36
Inrush Duration (µs)
800
Lamp Energy Label (class)
A
Nominal Frequency (Hz)
50/60Hz
Lifespan L70 B50
50000
Housing colour
Transparent
IP rating
IP20
Nominal Product Height (mm)
54
Nominal Product Diameter (mm)
50
Weight (kg)
0.046
Product EAN number
5410288319254
Packaging single length / height (cm)
6.1
Packaging single width (cm)
5.1
Packaging single depth (cm)
8.2
DUN14 (inner)
15410288319251
Units per inner package
6
Packaging inner length / height (cm)
19.4
Packaging inner width (cm)
11.1
Packaging inner depth (cm)
9.2
DUN14 (outer)
25410288319258
Units per outer package
60
Packaging outer length / height (cm)
58.5
Packaging outer width (cm)
20.8
Packaging outer depth (cm)
20.8
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Dimmable with approved dimmers
