REFLED SUPERIA RETRO ES50 V5 345LM DIM 927 36 SL
Item No:
0030721
Premium performance professional LED GU10 range with the same look and feel of traditional halogen GU10 lamp. Recreates backlight effect similar to halogen dichroic lamps. Full glass design - means no colours clashing between lamp and fixture. Very long lifetime of up to 25,000 hours. COOLFIT functionality – ensures overheat and over temperature protection. High switching cycles: >100,000. High colour rendering: CRI90. Dimmable. Warranty: 5 Years
Technical Assets
Dimensions (mm)
Photometrics
Product name
REFLED SUPERIA RETRO ES50 V5 345LM DIM 927 36 SL
Technology
LED
Lamp shape
Reflector
Cap/Base
GU10
Lamp finish
Fresnel lens
Built in presence detector
NONE
Fixture rating
Open
General application
Education, Hospitality, Museums & Galleries, Office, Residential & Consumer, Retail
Operating temperature range (°C)
-20°C...+50°C
Virtual assistant compatibility
N/A
ETIM Class
EC001959
E-number FI
4741217
Warranty
5 years
Useful luminous flux (Φuse)
345
Correlated colour temperature (k)
2700
Light colour
Homelight
CRI (Ra)
90
Colour Variation Initial (SDCM)
SDCM6
Luminous Intensity (cd)
600
Beam Angle (°)
36
Photobiological Risk Group
RG1
Power consumption (W)
3.6
Wattage (W)
3.7
Equivalent watt (W)
50
Supply current (A)
0.034
Primary Supply/Product voltage - min (V)
220.0
Primary Supply/Product voltage - max (V)
240.0
Control gear required
No
Control gear type
LED driver constant current
No. Of switching cycles before premature failures
>50000
Dimmable
Yes
Dimming method
Mains: leading / trailing edge
Inrush Current (A)
2.3
Inrush Duration (µs)
273
Lamp Energy Label (class)
E
Nominal Frequency (Hz)
50/60Hz
Lifespan L70 B50
25000
Housing colour
Transparent
IP rating
IP20
Nominal Product Height (mm)
54
Nominal Product Diameter (mm)
50
Weight (kg)
0.038
Product EAN number
5410288307213
Packaging single length / height (cm)
8.2
Packaging single width (cm)
6.1
Packaging single depth (cm)
5.1
DUN14 (inner)
15410288307210
Units per inner package
6
Packaging inner length / height (cm)
19.4
Packaging inner width (cm)
11.1
Packaging inner depth (cm)
9.2
DUN14 (outer)
25410288307217
Units per outer package
60
Packaging outer length / height (cm)
58.5
Packaging outer width (cm)
20.8
Packaging outer depth (cm)
20.8
Optimal operating condition (°C)
-20-50
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Dimmable with approved dimmers
