RefLED Superia Retro MR16 V3 460LM DIM 827 36 SL
Item No:
0031817
Premium performance professional LED MR16 range with the same look and feel of traditional halogen MR16 lamp. Recreates backlight effect similar to halogen dichroic lamps. Full glass design - means no colours clashing between lamp and fixture. Very long lifetime of up to 25,000 hours. Switching cycles: >100,000. Colour rendering: CRI80. Lamp voltage: 12V AC/DC. Dimmable on approved dimmers. Works with magnetic and compatible electronic transformers. Warranty: 5 Years
Technical Assets
Dimensions (mm)
Photometrics
Product name
RefLED Superia Retro MR16 V3 460LM DIM 827 36 SL
Technology
LED
Watt (Rated) (W)
5
Lamp shape
Reflector
Cap/Base
GU5.3
Lamp finish
Fresnel lens
Built in presence detector
NONE
Fixture rating
Open
General application
Education, Hospitality, Museums & Galleries, Office, Residential & Consumer, Retail
Virtual assistant compatibility
N/A
ETIM Class
EC001959
E-number FI
4741249
Warranty
5 years
Useful luminous flux (Φuse)
460
Correlated colour temperature (k)
2700
Light colour
Homelight
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM6
Luminous Intensity (cd)
900
Beam Angle (°)
36
Photobiological Risk Group
RG1
Power consumption (W)
5
Wattage (W)
5
Equivalent watt (W)
40
Supply current (A)
0.58
Primary Supply/Product voltage - min (V)
12.0
Primary Supply/Product voltage - max (V)
12.0
Control gear required
Yes
Control gear type
LED driver constant current
No. Of switching cycles before premature failures
>50000
Dimmable
Yes
Dimming method
Mains: leading / trailing edge
Inrush Current (A)
3.2
Inrush Duration (µs)
760
Lamp Energy Label (class)
F
Nominal Frequency (Hz)
50/60/HF
Lifespan L70 B50
25000
Housing colour
Transparent
IP rating
IP20
Nominal Product Height (mm)
44
Nominal Product Diameter (mm)
50
Weight (kg)
0.033
Product EAN number
5410288318172
Packaging single length / height (cm)
6.1
Packaging single width (cm)
5.1
Packaging single depth (cm)
8.2
DUN14 (inner)
15410288318179
Units per inner package
6
Packaging inner length / height (cm)
19.4
Packaging inner width (cm)
11.1
Packaging inner depth (cm)
9.2
DUN14 (outer)
25410288318176
Units per outer package
60
Packaging outer length / height (cm)
58.5
Packaging outer width (cm)
20.8
Packaging outer depth (cm)
20.8
Breakage cleaning instructions
Not applicable
Special purpose lamp
No
Dry applications use only
Yes
Suitable for household illumination
Yes
Safety message
Suitable for approved transf./dimmers
