START Flex IP20 830 2800lm
Item No:
0068100
To be replaced by 0068168
5 metre IP20 LED reel with pre-attached 3M adhesive type; equipped with 300 LEDs; 2800lm per 5m (560lm per 1m); 24V; 3000K; CRI80; SDCM ≤3;Compatible with emergency packs: 0046600, 0046601
Downloads
.jpg?maxheight=100&trim.threshold=200)
.jpg?maxheight=100&trim.threshold=200)
.jpg?maxheight=100&trim.threshold=200)
.jpg?maxheight=100&trim.threshold=200)
Technical Assets
Dimensions (mm)
Photometrics
Product name
START Flex IP20 830 2800lm
Technology
LED
Mount
Other
General application
Hospitality, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
ETIM Class
EC002706
E-number FI
4276594
Warranty
5 years
Useful luminous flux (Φuse)
2800
Fixture luminous flux (lm)
2800
Luminaire efficacy (lm/W)
117
Correlated colour temperature (k)
3000
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM3
Beam Angle (°)
120
Photobiological Risk Group
RG1
Power consumption (W)
24
Total power consumption (W)
24
Electrical protection
Class III
Control gear required
Yes
Dimmable
Yes
Dimming method
Other
Drive current (mA)
1000
Lamp Energy Label (class)
F
Lifespan L70 B50
54000
Lifespan L70 B10
54000
Lifespan L80 B10
50000
Lifespan L90 B10
44000
IP rating
IP20
IK rating
IK00
Nominal Product Length (mm)
5000
Nominal Product Width (mm)
8
Nominal Product Height (mm)
1.2
Weight (kg)
0.1
Product EAN number
5410288681009
Packaging single length / height (cm)
23.5
Packaging single width (cm)
22.5
Packaging single depth (cm)
3.0
DUN14 (inner)
15410288681006
Units per outer package
20
Packaging outer length / height (cm)
49.0
Packaging outer width (cm)
34.0
Packaging outer depth (cm)
24.0
Glow Wire Test (°C)
650
Optimal operating condition (°C)
-20-40
