START Flex IP20 830 10750lm
Item No:
0068114
To be replaced by 0068184
5 metre IP20 LED reel with pre-attached 3M adhesive type; equipped with 420 LEDs; 10750lm per 5m (2150lm per 1m); 24V; 3000K; CRI80; SDCM ≤3. Needs to be used with any aluminium profile for cooling LED chips purpose and therefore assuring longer lifetime ( Profile HO Surface 16 0022604 can be used) ;Compatible with emergency packs: 0046600, 0046601
Downloads
.jpg?maxheight=100&trim.threshold=200)
(2).jpg?maxheight=100&trim.threshold=200)
.jpg?maxheight=100&trim.threshold=200)
.jpg?maxheight=100&trim.threshold=200)
Technical Assets
Dimensions (mm)
Photometrics
Product name
START Flex IP20 830 10750lm
Technology
LED
Mount
Other
General application
Hospitality, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
ETIM Class
EC002706
E-number FI
4276900
Warranty
5 years
Useful luminous flux (Φuse)
10750
Fixture luminous flux (lm)
10750
Luminaire efficacy (lm/W)
130
Correlated colour temperature (k)
3000
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM3
Beam Angle (°)
120
Photobiological Risk Group
RG1
Power consumption (W)
82.5
Total power consumption (W)
82.5
Primary Supply/Product voltage - min (V)
24
Primary Supply/Product voltage - max (V)
24
Electrical protection
Class III
Control gear required
Yes
Dimmable
Yes
Dimming method
Other
Drive current (mA)
3438
Lamp Energy Label (class)
E
Lifespan L70 B50
54000
Lifespan L70 B10
54000
Lifespan L80 B10
50000
Lifespan L90 B10
44000
IP rating
IP20
IK rating
IK00
Nominal Product Length (mm)
5000
Nominal Product Width (mm)
10
Nominal Product Height (mm)
1.2
Weight (kg)
0.1
Product EAN number
5410288681146
Packaging single length / height (cm)
23.5
Packaging single width (cm)
22.5
Packaging single depth (cm)
3.0
DUN14 (inner)
15410288681143
Units per outer package
20
Packaging outer length / height (cm)
49.0
Packaging outer width (cm)
34.0
Packaging outer depth (cm)
24.0
Glow Wire Test (°C)
650
Optimal operating condition (°C)
-20-40
Accessories
-
Profile Recess 20 EF/U7 1m anodisedItem No: 0022587
-
Profile Semi Deep Surface 20 EF/T 1m anodisedItem No: 0022589
-
EMERGENCY PACK MANUAL TESTING 6V-55VItem No: 0046600
-
Profile Corner Surface 27 G/U 2m anodisedItem No: 0022603
-
Profile Shallow Narrow 14 EF/T 2m anodisedItem No: 0022601
-
Profile Shallow Wide Surface 30 CDE-9/T 3m anodisedItem No: 0022609
-
Profile Corner Surface 14 EF/T 1m anodisedItem No: 0022593
-
Profile Semi Deep Surface 20 EF/T 3m anodisedItem No: 0022607
-
Profile Recess 20 EF/U7 2m anodisedItem No: 0022596
-
Profile Deep Wide Suface 30 CDE-9/T 3m annodisedItem No: 0022608
-
EMERGENCY PACK SELF TEST/DALI MONITORING 6V-55VItem No: 0046601
-
Profile Semi Deep Surface 16 B/U4 1m anodisedItem No: 0022588
-
Flex Pro HO IP20 Straight Connector x 10Item No: 0068021
-
Flex Pro HO IP20 Connector x 5 + 2m LeadItem No: 0068022
-
Profile Corner Surface 27 G/U 3m anodisedItem No: 0022612
-
Profile Semi Deep Surface 16 B/U4 3m anodisedItem No: 0022606
-
Profile Recess 20 EF/U7 3m anodisedItem No: 0022605
-
Profile HO Surface 16 (20x4) raw alu. 2mItem No: 0022604
-
Profile Corner Surface 14 EF/T 3m anodisedItem No: 0022611
-
Profile Corner Surface 27 G/U 1m anodisedItem No: 0022594
-
Profile HO Surface 16 (20x4) raw alu. 3mItem No: 0022613
-
Profile Shallow Wide Surface 30 CDE-9/T 2m anodisedItem No: 0022600
-
Profile Shallow Narrow 14 EF/T 1m anodisedItem No: 0022592
-
Profile Semi Deep Surface 20 EF/T 2m anodisedItem No: 0022598
-
Profile Semi Deep Surface 16 B/U4 2m anodisedItem No: 0022597
-
Profile Deep Wide Surface 30 CDE-9/T 1m annodisedItem No: 0022590
-
Profile Shallow Wide Surface 30 CDE-9/T 1m anodisedItem No: 0022591
-
Profile HO Surface 16 (20x4) raw alu. 1mItem No: 0022595
-
Profile Deep Wide Surface 30 CDE-9/T 2m anodisedItem No: 0022599
-
Profile Corner Surface 14 EF/T 2m anodisedItem No: 0022602
-
Profile Shallow Narrow 14 EF/T 3m anodisedItem No: 0022610
-
Flex Pro HO IP20 Corner Connector x 10Item No: 0068023
