START Flex IP65 827 10250lm
Item No:
0068132
This product is no longer available
5 metre IP65 LED reel with pre-attached 3M adhesive type; equipped with 420 LEDs, 24V; 2700K; CRI80; SDCM ≤3;Compatible with emergency packs: 0046600, 0046601
Downloads
Technical Assets
Dimensions (mm)
Photometrics
Product name
START Flex IP65 827 10250lm
Technology
LED
Mount
Other
General application
Hospitality, Retail
Operating temperature range (°C)
-20°C...+40°C
Performance ambient temperature Tq (°C)
25
ETIM Class
EC002706
E-number FI
4276902
Warranty
5 years
Useful luminous flux (Φuse)
10250
Fixture luminous flux (lm)
10250
Luminaire efficacy (lm/W)
124
Correlated colour temperature (k)
2700
CRI (Ra)
80
Colour Variation Initial (SDCM)
SDCM3
Beam Angle (°)
120
Photobiological Risk Group
RG1
Power consumption (W)
82.5
Total power consumption (W)
82.5
Electrical protection
Class III
Control gear required
Yes
Dimmable
Yes
Dimming method
Other
Drive current (mA)
3438
Lamp Energy Label (class)
E
Lifespan L70 B50
54000
Lifespan L70 B10
54000
Lifespan L80 B10
50000
Lifespan L90 B10
44000
Housing colour
Beige
IP rating
IP65
IK rating
IK00
Nominal Product Length (mm)
5000
Nominal Product Width (mm)
12.5
Nominal Product Height (mm)
4
Weight (kg)
0.1
Product EAN number
5410288681320
Packaging single length / height (cm)
23.5
Packaging single width (cm)
22.5
Packaging single depth (cm)
3.0
DUN14 (inner)
15410288681327
Units per outer package
20
Packaging outer length / height (cm)
49.0
Packaging outer width (cm)
35.0
Packaging outer depth (cm)
24.0
Glow Wire Test (°C)
650
Optimal operating condition (°C)
-20-40
